Gear box-self made
Torque rating grade: 9≤T/A3≤13.5, high torque gear box, high grade domestic main components, NSK/INA brand bearings.
Imported gear box and safety clutch are optional, which can further improve the performance of machines.
Screw-self made
Screw element is with closely intermeshed design, block type and can be easily exchanged to suit different material.
Barrel-self made
Precision grade can reach to IT 6. It is benefit for energy reduction and block type design makes it possible for various combination.
 |  |  |
Gear box-self made
Torque rating grade: 9≤T/A3≤13.5, high torque gear box, high grade domestic main components, NSK/INA brand bearings.
Imported gear box and safety clutch are optional, which can further improve the performance of machines.
Screw-self made
Screw element is with closely intermeshed design, block type and can be easily exchanged to suit different material.
Barrel-self made
Precision grade can reach to IT 6. It is benefit for energy reduction and block type design makes it possible for various combination.
| | |
Model | Screw Diameter (mm) | L/D | Screw RPM | Main Motor KW | Torque Grade T/N3 | Output kg/h |
HT-26 | 26 | 32-68 | 300-900 | 7.5-22 | 11.2 | 30-80 |
HT-36 | 35.6 | 32-68 | 300-900 | 18.5-55 | 10.9 | 60-200 |
HT-42 | 41.2 | 32-68 | 300-900 | 30-90 | 11.6 | 100-300 |
HT-50 | 50.5 | 32-68 | 300-900 | 55-160 | 11.8 | 200-600 |
HT-63 | 62.4 | 32-68 | 300-900 | 110-315 | 12.3 | 350-1000 |
HT-72 | 71 | 32-68 | 300-900 | 160-450 | 11.8 | 600-2000 |
HT-85 | 81 | 32-68 | 300-900 | 220-630 | 11.2 | 800-2500 |
HT-95 | 93 | 32-68 | 300-900 | 355-900 | 11.8 | 1200-3000 |
HT-135 | 133 | 32-68 | 300-900 | 1000-3000 | 12 | 3500-10000 |
